Product Overview

ASRock B550 PHANTOM GAMING-ITX/AX

ASRock B550 PHANTOM GAMING-ITX/AX AM4 Mini-ITX DDR4 64 GB Motherboard

ASRock Motherboard $149.99

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketAM4
ChipsetB550
Form FactorMini-ITX
MemoryDDR4
Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

Seller Shipping Price
-
N/A Visit Store
-
N/A
-
N/A
Free
N/A Visit Store

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

Overview

The ASRock B550 PHANTOM GAMING-ITX/AX is a Mini-ITX motherboard for AM4. It supports DDR4 memory up to 5000 MT/s (OC).

  • Supports 3Rd Gen AMD AM4 Ryzen / Future AMD Ryzen Processors
  • 8 Power Phase Design, Digi Power, 90A Dr.MOS
  • Supports DDR4 5400+ (OC)
  • Graphics Output Options: HDMI, Displayport
  • 7.1 CH HD Audio (Realtek ALC1220 Audio Codec), Nahimic Audio

Specifications

Manufacturer ASRock
Model Number B550 PHANTOM GAMING-ITX/AX
Launch Date June 2020
CPU Socket AMD Socket AM4
Chipset Model Intel B550
Board Size / Form Factor Mini-ITX
Supported Memory Type DDR4
DIMM Slots 2
Maximum RAM Capacity 64 GB
Valid DDR4 Speeds DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2933 / DDR4-3200 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-3800 / DDR4-3866 / DDR4-4000 / DDR4-4133 / DDR4-4200 / DDR4-4266 / DDR4-4333 / DDR4-4400 / DDR4-4533 / DDR4-4600 / DDR4-4666 / DDR4-4800 / DDR4-4866 / DDR4-5000 (OC)
ECC Memory Support Yes * ECC memory support also depends on the CPU memory controller
Expansion Slots (PCIe) 1 × PCIe x16
PCIe x16 (Qty) 1
PCIe x4 (Qty) 0
PCIe x1 (Qty) 0
M.2 Slot Count 3 × M.2
M.2 Device Compatibility 2280 - M Key, 2280 - M Key, 2230 - E Key
SATA III Ports 4 × SATA 6Gbps
SATA Express Ports 0
Wired Networking (LAN) N/A
Onboard Wi-Fi Yes
Wi-Fi Standard 6 (802.11ax)
Rear-Panel USB USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers 0
Internal USB 3.2 Gen 2 Headers 1
Internal USB 3.2 Gen 1 Headers 1
Internal USB 2.0 Headers 1
NVIDIA SLI No
AMD CrossFire No
RAID Capability Yes
Back-Connect Layout No
Manufacturer Part Number (MPN) B550 PHANTOM GAMING-ITX/AX
SKU Code B550 PHANTOM GAMING-ITX/AX
GTIN / EAN 4710483931611
