ASRock X670E Taichi

ASRock X670E Taichi AM5 EATX DDR5 192 GB Motherboard

ASRock Motherboard $459.98

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketAM5

ChipsetX670E

Form FactorEATX

MemoryDDR5

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The ASRock X670E Taichi is a EATX motherboard for AM5. It supports DDR5 memory up to 6400 MT/s (OC).

ASRock X670E Taichi AM5 DDR5 AMD Ryzen 7000 X670E SATA 6Gb/s Extended ATX Motherboard Number of Memory Slots: 4x288pin (DDR5) Memory Standard: DDR5 6600+ (OC)* 1DPC 1R Up to 6600+ (OC), 4800 Natively. 1DPC 2R Up to 6000+ (OC), 4800 Natively. 2DPC 1R Up to 6000+ (OC), 4000 Natively. Onboard Video Chipset: Supported only by CPU with integrated graphic Audio Chipset: Realtek ALC4082 Audio Channels: 5.1 Channels Max LAN Speed: 10/100/1000/2500Mbps Maximum Memory Supported: 128GB Channel Supported: Dual Channel

Manufacturer	ASRock
Model Number	X670E Taichi
Launch Date	N/A
CPU Socket	AM5
Chipset Model	Intel X670E
Board Size / Form Factor	EATX
Supported Memory Type	DDR5
DIMM Slots	4
Maximum RAM Capacity	192 GB
Valid DDR4 Speeds	DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 / DDR5-6400 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	2 × PCIe x16
PCIe x16 (Qty)	2
PCIe x4 (Qty)	0
PCIe x1 (Qty)	0
M.2 Slot Count	5 × M.2
M.2 Device Compatibility	2280 - M Key, 2230 / 2242 / 2260 / 2280 / 22110 - M Key, 2280 - M Key, 2280 - M Key, 2230 - E Key
SATA III Ports	4 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	Yes
Wi-Fi Standard	6E (802.11ax, 6 GHz)
Rear-Panel USB	USB 3.2 Gen2x2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	1
Internal USB 3.2 Gen 2 Headers	0
Internal USB 3.2 Gen 1 Headers	2
Internal USB 2.0 Headers	2
NVIDIA SLI	No
AMD CrossFire	Yes
RAID Capability	No
Back-Connect Layout	No
Manufacturer Part Number (MPN)	X670E Taichi
SKU Code	X670E Taichi
GTIN / EAN	4710483940132
