ASRock Z790 LiveMixer

ASRock Z790 LiveMixer LGA1700 ATX DDR5 192 GB Motherboard

ASRock Motherboard $159.99

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketLGA1700

ChipsetZ790

Form FactorATX

MemoryDDR5

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The ASRock Z790 LiveMixer is a ATX motherboard for LGA1700. It supports DDR5 memory up to 6800 MT/s (OC).

ASRock Z790 LiveMixer LGA 1700 Intel Z790 SATA 6Gb/s DDR5 ATX Motherboards Memory Standard: Supports DDR5 non-ECC, un-buffered memory up to 6800+(OC)* 1DPC 1R Up to 6800+ MHz (OC), 4800 MHz Natively. 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively. 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively. 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively. - Supports Intel Extreme Memory Profile (XMP) 3.0 Number of Memory Slots: 4x288pin (DDR5) Audio Chipset: Realtek ALC897 Audio Codec - Nahimic Audio PCI Express 5.0 x16: 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* * If M2_1 is occupied, PCIE1 will downgrade to x8 mode. * Supports NVMe SSD as boot disks - Supports AMD CrossFire PCI Express 4.0 x16: 2 x PCIe 4.0 x16 Slots (PCIE3 and PCIE4), support x4 mode* Max LAN Speed: 2.5Gbps

Manufacturer	ASRock
Model Number	Z790 LiveMixer Z790 Live Mixer
Launch Date	October 2022
CPU Socket	LGA1700
Chipset Model	Intel Z790
Board Size / Form Factor	ATX
Supported Memory Type	DDR5
DIMM Slots	4
Maximum RAM Capacity	192 GB
Valid DDR4 Speeds	DDR5-4400 / DDR5-4800 / DDR5-5200 / DDR5-5600 / DDR5-6000 / DDR5-6200 / DDR5-6400 / DDR5-6800 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	3 × PCIe x16, 1 × PCIe x1
PCIe x16 (Qty)	3
PCIe x4 (Qty)	0
PCIe x1 (Qty)	1
M.2 Slot Count	6 × M.2
M.2 Device Compatibility	2260 / 2280 - M Key, 2260 / 2280 - M Key, 2260 / 2280 - M Key, 2242 / 2260 / 2280 - M Key, 2260 / 2280 - M Key, 2230 - E Key
SATA III Ports	4 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	No
Wi-Fi Standard	N/A
Rear-Panel USB	USB 3.2 Gen2x2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	1
Internal USB 3.2 Gen 2 Headers	0
Internal USB 3.2 Gen 1 Headers	2
Internal USB 2.0 Headers	2
NVIDIA SLI	No
AMD CrossFire	Yes
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	Z790 LiveMixer
SKU Code	Z790 LiveMixer
GTIN / EAN	4710483940897
