GIGABYTE TRX40 AORUS Master

GIGABYTE TRX40 AORUS Master sTRX4 EATX DDR4 256 GB Motherboard

Gigabyte Motherboard $499

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketsTRX4

ChipsetTRX40

Form FactorEATX

MemoryDDR4

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The GIGABYTE TRX40 AORUS Master is a EATX motherboard for sTRX4. It supports DDR4 memory up to 4400 MT/s (OC).

Supports 3Rd Gen AMD Ryzen Threadripper Processors
Quad Channel ECC/ Non-ECC Unbuffered DDR4 8 Dimms
16+3 Phases Infineon Digital VRM Solution With 70A Power Stage
Advanced Thermal Design With Fins-Array Heatsink Heatpipe With Extended Heatsink And Nanocarbon Baseplate
Aquantia 5Gbe LAN And Intel Gbe LAN With Cfosspeed

Manufacturer	Gigabyte
Model Number	TRX40 AORUS MASTER
Launch Date	November 2019
CPU Socket	sTRX4
Chipset Model	TRX40
Board Size / Form Factor	EATX
Supported Memory Type	DDR4
DIMM Slots	8
Maximum RAM Capacity	256 GB
Valid DDR4 Speeds	DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2933 / DDR4-3200 / DDR4-3300 / DDR4-3333 / DDR4-3400 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-3866 / DDR4-4000 / DDR4-4133 / DDR4-4266 / DDR4-4400 (OC)
ECC Memory Support	Yes * ECC memory support also depends on the CPU memory controller
Expansion Slots (PCIe)	4 × PCIe x16, 1 × PCIe x1
PCIe x16 (Qty)	4
PCIe x4 (Qty)	0
PCIe x1 (Qty)	1
M.2 Slot Count	3 × M.2
M.2 Device Compatibility	2260 / 2280 / 22110 - M Key, 2280 - M Key, 2280 - M Key
SATA III Ports	8 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	GbE LAN
Onboard Wi-Fi	Yes
Wi-Fi Standard	6 (802.11ax)
Rear-Panel USB	USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	0
Internal USB 3.2 Gen 2 Headers	1
Internal USB 3.2 Gen 1 Headers	2
Internal USB 2.0 Headers	2
NVIDIA SLI	Yes
AMD CrossFire	Yes
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	TRX40 AORUS MASTER
SKU Code	TRX40 AORUS MASTER
GTIN / EAN	889523020166
