Colorful CVN B760I FROZEN WIFI V20

Colorful CVN B760I FROZEN WIFI V20 LGA1700 Mini-ITX DDR4 64 GB Motherboard

Colorful Motherboard $229.58

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketLGA1700

ChipsetB760

Form FactorMini-ITX

MemoryDDR4

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The Colorful CVN B760I FROZEN WIFI V20 is a Mini-ITX motherboard for LGA1700. It supports DDR4 memory up to 4800 MT/s (OC).

RAID Supported: YES Processor compatibility: 13th Intel Core i7,Intel Core i7,12th Intel Core i5,13th Intel Core i5,12th Intel Core i3 Usage Scenario: Enthusiast & Overclocking,Gaming,Audio & Video,Office,Video Production,Workstation,Server,MINI PC,Scientific Computing,3-D Modeling,Video Rendering Special Function: RGB,Cooling Armor,NONE Back I/O Ports: 4 x USB 2.0,USB 3.2 Gen2 X2,HDMI 2.0 Onboard LAN: WIFI 6 (AX),Bluetooth v5.1 Supports M.2 SSD: 2280 Storage Interface Type: M.2 (NVMe)

Manufacturer	Colorful
Model Number	CVN B760I FROZEN WIFI V20
Launch Date	N/A
CPU Socket	LGA1700
Chipset Model	Intel B760
Board Size / Form Factor	Mini-ITX
Supported Memory Type	DDR4
DIMM Slots	2
Maximum RAM Capacity	64 GB
Valid DDR4 Speeds	DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-2933 / DDR4-3000 / DDR4-3200 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-4000 / DDR4-4266 / DDR4-4400 / DDR4-4600 / DDR4-4800 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	1 × PCIe x16
PCIe x16 (Qty)	1
PCIe x4 (Qty)	0
PCIe x1 (Qty)	0
M.2 Slot Count	2 × M.2
M.2 Device Compatibility	2280 - M Key, 2280 - M Key
SATA III Ports	4 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	Yes
Wi-Fi Standard	6 (802.11ax)
Rear-Panel USB	USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	0
Internal USB 3.2 Gen 2 Headers	1
Internal USB 3.2 Gen 1 Headers	1
Internal USB 2.0 Headers	1
NVIDIA SLI	No
AMD CrossFire	No
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	CVN B760I FROZEN WIFI V20
SKU Code	CVN B760I FROZEN WIFI V20
GTIN / EAN	6970417595533
