MSI MPG B760I EDGE WIFI

MSI MPG B760I EDGE WIFI LGA1700 Mini-ITX DDR5 96 GB Motherboard

MSI Motherboard $180.44

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketLGA1700

ChipsetB760

Form FactorMini-ITX

MemoryDDR5

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The MSI MPG B760I EDGE WIFI is a Mini-ITX motherboard for LGA1700. It supports DDR5 memory up to 7200 MT/s (OC).

MSI MPG B760I EDGE WIFI LGA 1700 Intel B760 SATA 6Gb/s Mini ITX Motherboard Number of Memory Slots: 2x288pin (DDR5) PCI Express x16: 1 x PCI Express x16 Audio Chipset: Realtek ALC897 CPU Type: Supports 12th / 13th Gen Intel Core Processors, Pentium Gold and Celeron Processors Maximum Memory Supported: 64GB Channel Supported: Dual Channel M.2: 1 x Key M (CPU PCIe) 1 x Key M (PCIe/SATA) 1 x Key E (WiFi/BT) Audio Channels: 8 Channels

Manufacturer	MSI
Model Number	MPG B760I EDGE WIFI
Launch Date	N/A
CPU Socket	LGA1700
Chipset Model	Intel B760
Board Size / Form Factor	Mini-ITX
Supported Memory Type	DDR5
DIMM Slots	2
Maximum RAM Capacity	96 GB
Valid DDR4 Speeds	DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 / DDR5-6400 / DDR5-6600 / DDR5-6800 / DDR5-7000 / DDR5-7200 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	1 × PCIe x16
PCIe x16 (Qty)	1
PCIe x4 (Qty)	0
PCIe x1 (Qty)	0
M.2 Slot Count	2 × M.2
M.2 Device Compatibility	2280 - M Key, 2280 - M Key
SATA III Ports	4 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	Yes
Wi-Fi Standard	6E (802.11ax, 6 GHz)
Rear-Panel USB	USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	0
Internal USB 3.2 Gen 2 Headers	1
Internal USB 3.2 Gen 1 Headers	1
Internal USB 2.0 Headers	1
NVIDIA SLI	No
AMD CrossFire	No
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	MPG B760I EDGE WIFI
SKU Code	MPG B760I EDGE WIFI
GTIN / EAN	824142315545
