MSI MPG Z390I GAMING EDGE AC

MSI MPG Z390I GAMING EDGE AC LGA1151 Mini-ITX DDR4 64 GB Motherboard

MSI Motherboard $205

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketLGA1151

ChipsetZ390

Form FactorMini-ITX

MemoryDDR4

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The MSI MPG Z390I GAMING EDGE AC is a Mini-ITX motherboard for LGA1151. It supports DDR4 memory up to 4600 MT/s (OC).

Supports 9th i9-9900K, i7-9700K, i5-9600K and 8th Generation Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket
Supports dual channel DDR4 Memory, up to 4600(OC) MHz
2x TURBO M.2, Intel Optane Memory Ready. Turbo USB 3.1 GEN2
AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
Built for high-performance small-form factor builds - Extended heatsink, mini-ITX form factor

Manufacturer	MSI
Model Number	MPG Z390I GAMING EDGE AC
Launch Date	N/A
CPU Socket	LGA1151
Chipset Model	Intel Z390
Board Size / Form Factor	Mini-ITX
Supported Memory Type	DDR4
DIMM Slots	2
Maximum RAM Capacity	64 GB
Valid DDR4 Speeds	DDR4-2133 / DDR4-2400 / DDR4-2666 / DDR4-2800 / DDR4-3000 / DDR4-3200 / DDR4-3300 / DDR4-3333 / DDR4-3400 / DDR4-3466 / DDR4-3600 / DDR4-3733 / DDR4-3866 / DDR4-4000 / DDR4-4133 / DDR4-4200 / DDR4-4266 / DDR4-4400 / DDR4-4500 / DDR4-4600 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	1 × PCIe x16
PCIe x16 (Qty)	1
PCIe x4 (Qty)	0
PCIe x1 (Qty)	0
M.2 Slot Count	2 × M.2
M.2 Device Compatibility	2260 / 2280 - M Key, 2260 / 2280 - M Key
SATA III Ports	4 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	Yes
Wi-Fi Standard	5
Rear-Panel USB	USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	0
Internal USB 3.2 Gen 2 Headers	0
Internal USB 3.2 Gen 1 Headers	1
Internal USB 2.0 Headers	1
NVIDIA SLI	No
AMD CrossFire	No
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	MPG Z390I GAMING EDGE AC
SKU Code	MPG Z390I GAMING EDGE AC
GTIN / EAN	824142169650
