EVGA Z790 CLASSIFIED

EVGA Z790 CLASSIFIED LGA1700 EATX DDR5 128 GB Motherboard

EVGA Motherboard $697.19

Compare seller pricing, scan the quick specs, and size this part up before adding it to your next build.

SocketLGA1700

ChipsetZ790

Form FactorEATX

MemoryDDR5

Retailer links open in a new tab. Pricing can change quickly, so treat this page as a shortlist and confirm the final price with the seller.

Retailers

Live seller links for quick price checks.

PC Builder may earn a small commission when you buy through links on our site.

Prices and availability can change without notice and are confirmed at checkout with the seller.

The EVGA Z790 CLASSIFIED is a EATX motherboard for LGA1700. It supports DDR5 memory up to 7800 MT/s (OC).

Intel Z790 Chipset, Supports 13th and 12th Gen Intel Core processors for LGA1700 socket
PCIe Gen5, M.2 Gen4, EATX Form Factor, 12 Layer PCB, 19 Phase PWM, Metal Reinforced PCIe Slots, Preinstalled rear I/O cover
4 DIMM Dual-Channel supports up to 128GB 7800MHz+(OC), 2 USB4 (Type-C) Ports, 7 USB 3.2 Gen2 Ports (6x Type A, 1x Type-C Header)
8 SATA 6Gb/s, 3x M.2 Key-M 80mm, 1x M.2 Key-E 32mm with installed WiFi 6E/BT 5.2, 2x DP 1.4 + HDR outputs (via USB4 Type-C), Marvel 10 Gb/s + Intel 2.5 Gb/s NICs
Onboard ARGB lighting + 4x ARGB Headers fully customizable through EVGA ELEET X1

Manufacturer	EVGA
Model Number	121-RL-E798-KR 121-AL-E798-KR
Launch Date	N/A
CPU Socket	LGA1700
Chipset Model	Intel Z790
Board Size / Form Factor	EATX
Supported Memory Type	DDR5
DIMM Slots	4
Maximum RAM Capacity	128 GB
Valid DDR4 Speeds	DDR5-4800 / DDR5-5000 / DDR5-5200 / DDR5-5400 / DDR5-5600 / DDR5-5800 / DDR5-6000 / DDR5-6200 / DDR5-6400 / DDR5-6600 / DDR5-6800 / DDR5-7000 / DDR5-7200 / DDR5-7400 / DDR5-7600 / DDR5-7800 (OC)
ECC Memory Support	No
Expansion Slots (PCIe)	1 × PCIe x16, 1 × PCIe x4
PCIe x16 (Qty)	1
PCIe x4 (Qty)	1
PCIe x1 (Qty)	0
M.2 Slot Count	4 × M.2
M.2 Device Compatibility	2280 - M Key, 2280 - M Key, 2280 - M Key, 2230 - E Key
SATA III Ports	8 × SATA 6Gbps
SATA Express Ports	0
Wired Networking (LAN)	N/A
Onboard Wi-Fi	Yes
Wi-Fi Standard	6E (802.11ax, 6 GHz)
Rear-Panel USB	USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0
Internal USB 3.2 Gen 2x2 Headers	0
Internal USB 3.2 Gen 2 Headers	1
Internal USB 3.2 Gen 1 Headers	1
Internal USB 2.0 Headers	1
NVIDIA SLI	No
AMD CrossFire	No
RAID Capability	Yes
Back-Connect Layout	No
Manufacturer Part Number (MPN)	121-RL-E798-KR
SKU Code	121-RL-E798-KR
GTIN / EAN	843368076924
